OEM Norsat 5G Filter Quality 3700-4200MHz Anti-Interference C Band 5G Filter FT6B37420010
Electrical Specifications
| Electrical Specifications | |||
| Type No. |
FT6B37420010 |
||
| Frequency Band (MHz) |
3700-4200 |
||
| Insertion Loss (dB)(Full temperature,Outcluding connectors) |
≤1.5@3700&4200MHz,≤0.5@3800-4100MHz |
||
| Rejection (dB) |
≥60@3.5GHz,≥60@3.6GHz,≥60@3.67GHz,≥60@3.68GHz,≥30@4.23GHz,≥40@4.25GHz |
||
| Return Loss (dB)/VSWR |
≤-17/1.38:1 |
||
| Input Power (W) |
<100 |
||
| Grorp Delay(ns) |
16(Within +/-5MHz) |
||
| Impedance (Ω) |
50 |
||
| Mechanical Specifications | Environmental & Compliance | ||
| Dimensions,HxWxD (mm) |
130x98.4x69.9 |
Operational Temperature (°C) |
-40 to +65 |
| Weight (kg) |
0.85 |
Operational Humidity (%) |
≤95 |
| Packing Size(mm) |
200x170x130 |
Environment |
IP66 |
| Connector Type |
CPR-229G(input),CPR-229F(output) |
Application |
Indoor and Outdoor |
| Color |
Apple White |
RoHS |
Compliant |
| Mounting |
Plane mounting |
||
| Outline Drawing | |||
Media Networks
Ensures stable communication channels for newspapers and media organizations.
Military Systems
Protects vital military communications from signal disruption.
Aviation Communications
Boosts the dependability of communication systems in civil aviation operations.
Hospitality Industry
Safeguards hotel communication networks from interference caused by 5G signals.
