OEM Norsat 5G Filter Quality 3700-4200MHz Anti-Interference C band 5G Filter FT6B37420020

The FT6B37420020 is an advanced 5G interference filter designed to effectively block interference from 5G base stations operating in the 3700-4200MHz C-band spectrum. It delivers superior signal isolation, is built for durability, and is simple to install, making it a perfect solution for protecting satellite communications from 5G signal disturbances.


♦ Pass band: 3700-4200MHz
♦ Suitable for indoor and outdoor applications
♦ Plane mounting
♦ Connector Type, Flange

    Electrical Specifications

    Electrical Specifications
    Type No.

    FT6B37420020

    Frequency Band (MHz)

    3700-4200

    Insertion Loss (dB)(Full temperature,Outcluding connectors)

    ≤0.85@3700-3730MHz,≤0.55@3730-4200MHz

    Rejection (dB)

    ≥70@Below3500MHz,≥60@3500-3550MHz,≥45@3550-3650MHz, ≥48@4350-4400MHz,≥65@4400-4800MHz

    Return Loss (dB)/VSWR

    ≤-16/1.4:1

    Input Power (W)

    <100

    Grorp Delay(ns)

    /

    Impedance (Ω)

    50

    Mechanical Specifications Environmental & Compliance
    Dimensions,HxWxD (mm)

    120x98.4x69.9

    Operational Temperature (°C)

    0 to +55

    Weight (kg)

    0.65

    Operational Humidity (%)

    ≤95

    Packing Size(mm)

    190x170x130

    Environment

    IP66

    Connector Type

    CPR-229G(input),CPR-229F(output)

    Application

    Indoor and Outdoor

    Color

    Apple White

    RoHS

    Compliant

    Mounting

    Plane mounting

    Outline Drawing
    • products1k5z
    • products2l4i

    Why Choose Us

    Design & Manufacturing

    German engineering with Chinese production for cost efficiency.

    RF Expertise

    Over 25 years of experience in RF technology.

    Certified Quality

    CE, ROHS, and ISO9001 certifications for all products.

    Global Warehouses

    Warehouses in Germany, South Africa, Dubai, and India for quick deliveries.

    One-Stop Service

    Complete support for CATV, Satellite TV, FTTH systems, and accessories.

    Local Support

    Professional teams for after-sales service in various regions.

    Quality Guarantee

    2-year warranty for assured product reliability.

    PERFORMANCE CHARACTERISTICS

    The FT6B37420020 comes equipped with a range of features that make it a dependable and highly efficient solution for addressing 5G signal interference:

    • OEM Norsat 5G filter Quality 3dlt
    • OEM Norsat 5G filter Quality 3zl3
    • OEM Norsat 5G filter Quality 3m28
