OEM Norsat 5G filter Quality 3700-4200MHz anti-interference C band 5G filter FT6B37420250

The FT6B37420250 represents a sophisticated 5G interference mitigation device, specifically crafted to neutralize interference from 5G base stations within the 3700-4200MHz C-band frequency range. This filter ensures exceptional signal separation, is constructed for long-lasting resilience, and features an easy installation process, rendering it an ideal choice for safeguarding satellite communication systems against 5G signal interference.



♦ Pass band: 3700-4200MHz
♦ Suitable for indoor and outdoor applications
♦ Plane mounting
♦ Connector Type,Flange

    Electrical Specifications

    Electrical Specifications

    Type No.

    FT6B37420250

    Frequency Band (MHz)

    3700-4200

    Insertion Loss (dB)(Full temperature,Outcluding connectors)

    0.5 max

    Rejection (dB)

    ≥60@3000-3600MHz,≥60@4.4-4.5MHz

    Return Loss (dB)/VSWR

    ≤-21/1.2:1

    Input Power (W)

    <100

    Mechanical Specifications

    Environmental & Compliance

    Dimensions,HxWxD (mm)

    120x98.4x69.9

    Operational Temperature (°C)

    -40 to +65

    Weight (kg)

    0.65

    Operational Humidity (%)

    ≤95

    Packing Size(mm)

    190x170x130

    Environment

    IP67

    Connector Type

    CPR-229G(input),CPR-229F(output)

    Application

    Indoor and Outdoor

    Color

    Apple White

    RoHS

    Compliant

    Mounting

    Plane mounting

    Finish

    UV resistant Epoxy

    Outline Drawing

    • C band 5G filter FT6B37420230pcg

    Why Choose Us

    Manufacturing Excellence

    We combine German precision with Chinese production techniques to achieve the best cost efficiency.

    RF Expertise

    With over 25 years of experience in RF technology, we have a deep understanding of the field.

    Certified Quality

    Our products are certified by CE, ROHS, and ISO9001, ensuring they meet the highest quality standards.

    Global Distribution Network

    Our distribution centers in key locations such as Germany, South Africa, Dubai, and India ensure fast and efficient shipping

    Complete Service Offering

    We provide a comprehensive suite of services for CATV, Satellite TV, FTTH systems, and associated accessories.

    Localized Support

    We have dedicated teams ready to offer post-purchase support in various regions.

    Reliability Commitment

    We stand behind our products with a 2-year warranty, ensuring their longevity and reliability.

    PERFORMANCE CHARACTERISTICS

    The FT6B37420250 features an array of advanced functionalities, making it a reliable and efficient choice for mitigating 5G signal interference:

    • OEM Norsat 5G filter Quality 3dlt
    • OEM Norsat 5G filter Quality 3zl3
    • OEM Norsat 5G filter Quality 3m28
