OEM Norsat 5G filter Quality 3700-4700MHz anti-interference C band 5G filter FT6B37480010
Electrical Specifications
Electrical Specifications | |||
Type No. |
FT6B37480010 |
||
Frequency Band (MHz) |
3700-4700 |
||
Insertion Loss (dB)(Full temperature,Outcluding connectors) |
0.3 typ@F0,0.8 typ@Band Edges |
||
Rejection (dB) |
≥75@3200-3600,≥75@4800-5000 |
||
Return Loss (dB)/VSWR |
≤-16/1.4:1 |
||
Input Power (W) |
<50 |
||
Mechanical Specifications |
Environmental & Compliance |
||
Dimensions,HxWxD (mm) |
160x98.4x69.9 |
Operational Temperature (°C) |
-40 to +65 |
Weight (kg) |
0.7 |
Operational Humidity (%) |
≤95 |
Packing Size(mm) |
235x170x120 |
Environment |
IP66 |
Connector Type |
CPR-229G(input),CPR-229F(output) |
Application |
Indoor and Outdoor |
Color |
Apple White |
RoHS |
Compliant |
Mounting |
Plane mounting |
|
|
Outline Drawing |
Electrical Specifications | |||
Type No. |
FT6B37420260 |
||
Frequency Band (MHz) |
3700-4200 |
||
Insertion Loss (dB)(Full temperature,Outcluding connectors) |
0.4,typ.,1.0max |
||
Rejection (dB) |
≥70@3000-3600MHz,≥50@3600-3680MHz, ≥15@4250-4400MHz, ≥70@4400-5000MHz |
||
Return Loss (dB)/VSWR |
≤-18/1.3:1 |
||
Input Power (W) |
<100 |
||
Mechanical Specifications |
Environmental & Compliance |
||
Dimensions,HxWxD (mm) |
170x98.5x69.9 |
Operational Temperature (°C) |
-40 to +65 |
Weight (kg) |
0.8 |
Operational Humidity (%) |
≤95 |
Packing Size(mm) |
235x170x120 |
Environment |
IP67 |
Connector Type |
CPR-229G(input),CPR-229F(output) |
Application |
Indoor and Outdoor |
Color |
Apple White |
RoHS |
Compliant |
Mounting |
Plane mounting |
Finish |
UV resistant Epoxy |
Outline Drawing |
