OEM Norsat 5G filter Quality 3720-4200MHz anti-interference C band 5G filter FT6B37420100-V01

The FT6B37420100-V01 represents a cutting-edge 5G interference filter crafted to efficiently block interference emanating from 5G base stations within the 3720-4200 MHz C-band range. It ensures remarkable signal isolation, is constructed for long-lasting performance, and is easy to install, making it an optimal solution for defending satellite communications against 5G signal interference.



♦ Pass band: 3720-4200
♦ Suitable for indoor and outdoor applications
♦ Plane mounting
♦ Connector Type,Flange

    Electrical Specifications

    Electrical Specifications

    Type No.

    FT6B37420100-V01

    Frequency Band (MHz)

    3720-4200

    Insertion Loss (dB)(Full temperature,Outcluding connectors)

    1.25 max,1.1 typ

    Rejection (dB)

    60 Min below 3700MHz,≥40 Min below 4230MHz,

    Return Loss (dB)/VSWR

    ≤-20/1.23:1

    Input Power (W)

    <100

    Grorp Delay(ns)

    2.5 nSec Max within±0.5

    Mechanical Specifications

    Environmental & Compliance

    Dimensions,HxWxD (mm)

    171.5x98.4x69.9

    Operational Temperature (°C)

    -40 to +50

    Weight (kg)

    1

    Operational Humidity (%)

    ≤95

    Packing Size(mm)

    250x170x130

    Environment

    IP66

    Connector Type

    CPR-229G(input),CPR-229F(output)

    Application

    Indoor and Outdoor

    Color

    Apple White

    RoHS

    Compliant

    Mounting

    Plane mounting





    Outline Drawing

    Electrical Specifications

    Type No.

    FT6B37420260

    Frequency Band (MHz)

    3700-4200

    Insertion Loss (dB)(Full temperature,Outcluding connectors)

    0.4,typ.,1.0max

    Rejection (dB)

    ≥70@3000-3600MHz,≥50@3600-3680MHz,

    ≥15@4250-4400MHz, ≥70@4400-5000MHz

    Return Loss (dB)/VSWR

    ≤-18/1.3:1

    Input Power (W)

    <100

    Mechanical Specifications

    Environmental & Compliance

    Dimensions,HxWxD (mm)

    170x98.5x69.9

    Operational Temperature (°C)

    -40 to +65

    Weight (kg)

    0.8

    Operational Humidity (%)

    ≤95

    Packing Size(mm)

    235x170x120

    Environment

    IP67

    Connector Type

    CPR-229G(input),CPR-229F(output)

    Application

    Indoor and Outdoor

    Color

    Apple White

    RoHS

    Compliant

    Mounting

    Plane mounting

    Finish

    UV resistant Epoxy

    Outline Drawing

    • C band 5G filter FT6B37420130zkm
