OEM Norsat 5G filter Quality 3720-4800MHz anti-interference C band 5G filter FT6B37480020
Electrical Specifications
Electrical Specifications | |||
Type No. |
FT6B37480020 |
||
Frequency Band (MHz) |
3720-4800 |
||
Insertion Loss (dB)(Full temperature,Outcluding connectors) |
≤1.3@3720MHz,≤0.8@4800MHz,≤0.3@3800-4700MHz |
||
Rejection (dB) |
≥20@3700MHz,≥55@3680MHz,≥50@3660MHz,≥60@3620MHz,≥65@3570MHz,≥70@3520MHz,≥20@4850MHz |
||
Return Loss (dB)/VSWR |
≤-16/1.4:1 |
||
Input Power (W) |
<50 |
||
Mechanical Specifications |
Environmental & Compliance |
||
Dimensions,HxWxD (mm) |
160x98.4x69.9 |
Operational Temperature (°C) |
-40 to +65 |
Weight (kg) |
0.7 |
Operational Humidity (%) |
≤95 |
Packing Size(mm) |
235x170x120 |
Environment |
IP66 |
Connector Type |
CPR-229G(input),CPR-229F(output) |
Application |
Indoor and Outdoor |
Color |
Apple White |
RoHS |
Compliant |
Mounting |
Plane mounting |
|
|
Outline Drawing | |||
Electrical Specifications | |||
Type No. |
FT6B37420260 |
||
Frequency Band (MHz) |
3700-4200 |
||
Insertion Loss (dB)(Full temperature,Outcluding connectors) |
0.4,typ.,1.0max |
||
Rejection (dB) |
≥70@3000-3600MHz,≥50@3600-3680MHz, ≥15@4250-4400MHz, ≥70@4400-5000MHz |
||
Return Loss (dB)/VSWR |
≤-18/1.3:1 |
||
Input Power (W) |
<100 |
||
Mechanical Specifications |
Environmental & Compliance |
||
Dimensions,HxWxD (mm) |
170x98.5x69.9 |
Operational Temperature (°C) |
-40 to +65 |
Weight (kg) |
0.8 |
Operational Humidity (%) |
≤95 |
Packing Size(mm) |
235x170x120 |
Environment |
IP67 |
Connector Type |
CPR-229G(input),CPR-229F(output) |
Application |
Indoor and Outdoor |
Color |
Apple White |
RoHS |
Compliant |
Mounting |
Plane mounting |
Finish |
UV resistant Epoxy |
Outline Drawing | |||
Media Networks
Guarantees reliable communication channels for news agencies and media organizations, preventing interference from 5G.
Military Systems
Safeguards critical military communications from signal disruption and interference, ensuring secure operations.
Aviation Communications
Enhances the reliability of communication systems in civil aviation, ensuring seamless in-flight communication.
Hospitality Industry
Protects hotel communication networks from dis
