OEM Norsat 5G filter Quality 3820-4200MHz anti-interference C band 5G filter FT6B38420030-V01

The FT6B38420030-V01 serves as a high-performance interference filter specifically aimed at countering 5G signal disruptions from base stations within the 3820-4200MHz C-band range. Offering excellent signal isolation and a durable design, it allows for effortless installation, rendering it a perfect solution for protecting satellite communications against 5G interference.



♦ Pass band: 3820-4200
♦ Suitable for indoor and outdoor applications
♦ Plane mounting
♦ Connector Type,Flange

    Electrical Specifications

    Electrical Specifications

    Type No.

    FT6B38420030-V01

    Frequency Band (MHz)

    3820-4200

    Insertion Loss (dB)(Full temperature,Outcluding connectors)

    1.35 max,1.1 typ

    Rejection (dB)

    70 Min below 3700MHz,60 Min at 3800MHz,50 Min at 3803MHz,

    25 Min above 4230MHz

    Return Loss (dB)/VSWR

    ≤-20/1.23:1

    Input Power (W)

    <100

    Grorp Delay(ns)

    2.5 nSec Max within±0.5

    Mechanical Specifications

    Environmental & Compliance

    Dimensions,HxWxD (mm)

    171.5x98.4x69.9

    Operational Temperature (°C)

    -40 to +50

    Weight (kg)

    1

    Operational Humidity (%)

    ≤95

    Packing Size(mm)

    250x170x130

    Environment

    IP66

    Connector Type

    CPR-229G(input),CPR-229F(output)

    Application

    Indoor and Outdoor

    Color

    Apple White

    RoHS

    Compliant

    Mounting

    Plane mounting





    Outline Drawing

    Electrical Specifications

    Type No.

    FT6B37420260

    Frequency Band (MHz)

    3700-4200

    Insertion Loss (dB)(Full temperature,Outcluding connectors)

    0.4,typ.,1.0max

    Rejection (dB)

    ≥70@3000-3600MHz,≥50@3600-3680MHz,

    ≥15@4250-4400MHz, ≥70@4400-5000MHz

    Return Loss (dB)/VSWR

    ≤-18/1.3:1

    Input Power (W)

    <100

    Mechanical Specifications

    Environmental & Compliance

    Dimensions,HxWxD (mm)

    170x98.5x69.9

    Operational Temperature (°C)

    -40 to +65

    Weight (kg)

    0.8

    Operational Humidity (%)

    ≤95

    Packing Size(mm)

    235x170x120

    Environment

    IP67

    Connector Type

    CPR-229G(input),CPR-229F(output)

    Application

    Indoor and Outdoor

    Color

    Apple White

    RoHS

    Compliant

    Mounting

    Plane mounting

    Finish

    UV resistant Epoxy

    Outline Drawing

    • C band 5G filter FT6B37420130

    applications

    Satellite Stations

    Assures steady satellite signal reception, enabling uninterrupted radio and television broadcasting.

    Meteorology

    Safeguards the transmission of weather data against 5G interference, ensuring consistent and reliable information flow.

    Financial Networks

    Protects the transmission of live financial data from disruptions triggered by 5G signals.

    Media Networks

    Ensures media networks maintain stable communication channels, avoiding any disturbances caused by 5G interference.

    Military Systems

    Defends critical military communications, ensuring they remain undisturbed by external 5G signals.

    Aviation Communications

    Strengthens the reliability of communication systems in the aviation industry, ensuring smooth, continuous communication.

    Hospitality Industry

    Protects hotel communication systems from 5G signal disruptions, ensuring seamless communication and operations.

    PERFORMANCE CHARACTERISTICS

    The FT6B38420030-V01 comes equipped with numerous features that make it a reliable and efficient solution for 5G signal interference mitigation:
