OEM Norsat 5G filter Quality 4000-4200MHz anti-interference C band 5G filter FT6B40420010
Electrical Specifications
Electrical Specifications | |||
Type No. |
FT6B40420010 |
||
Frequency Band (MHz) |
4000-4200 |
||
Insertion Loss (dB)(Full temperature,Outcluding connectors) |
0.7typ.,1.5max |
||
Rejection (dB) |
≥10@3300-3980MHz,≥40@4250-5000MHz |
||
Return Loss (dB)/VSWR |
≤-16/1.4:1 |
||
Mechanical Specifications | Environmental & Compliance | ||
Dimensions,HxWxD (mm) |
170x98.5x69.9 |
Operational Temperature (°C) |
-40 to +65 |
Weight (kg) |
0.8 |
Operational Humidity (%) |
≤95 |
Packing Size(mm) |
235x170x120 |
Environment |
IP67 |
Connector Type |
CPR-229G(input),CPR-229F(output) |
Application |
Indoor and Outdoor |
Color |
Apple White |
RoHS |
Compliant |
Mounting |
Plane mounting |
Finish |
UV resistant Epoxy |
Outline Drawing |
Electrical Specifications | |||
Type No. |
FT6B37420260 |
||
Frequency Band (MHz) |
3700-4200 |
||
Insertion Loss (dB)(Full temperature,Outcluding connectors) |
0.4,typ.,1.0max |
||
Rejection (dB) |
≥70@3000-3600MHz,≥50@3600-3680MHz, ≥15@4250-4400MHz, ≥70@4400-5000MHz |
||
Return Loss (dB)/VSWR |
≤-18/1.3:1 |
||
Input Power (W) |
<100 |
||
Mechanical Specifications |
Environmental & Compliance |
||
Dimensions,HxWxD (mm) |
170x98.5x69.9 |
Operational Temperature (°C) |
-40 to +65 |
Weight (kg) |
0.8 |
Operational Humidity (%) |
≤95 |
Packing Size(mm) |
235x170x120 |
Environment |
IP67 |
Connector Type |
CPR-229G(input),CPR-229F(output) |
Application |
Indoor and Outdoor |
Color |
Apple White |
RoHS |
Compliant |
Mounting |
Plane mounting |
Finish |
UV resistant Epoxy |
Outline Drawing |
Media Reliability
Ensures consistent and interference-free transmission for news outlets, maintaining the integrity of media broadcasts.
Military-Grade Protection
Delivers high-level signal isolation for military communications, ensuring both reliability and confidentiality during operations.
Aviation Communication Safety
Essential for air traffic management, the filter preserves clear and consistent communication, enhancing overall flight safety.
Hospitality Service Continuity
Improves guest experiences by guaranteeing uninterrupted satellite TV and communication services within the hospitality industry.
