OEM Norsat 5G filter Quality 4500-4800MHz anti-interference C band 5G filter FT6B45480010

The FT6B45480010 is a state-of-the-art interference filter tailored for high-performance applications, specifically targeting the elimination of interference from 5G base stations operating in the C-band frequency range of 4500-4800MHz. It delivers exceptional signal isolation, is built to withstand the test of time, and offers a user-friendly installation process, making it the perfect choice for defending satellite communications against 5G interference.



♦ Pass band: 4500-4800
♦ Suitable for indoor and outdoor applications
♦ Plane mounting
♦ Connector Type,Flange

    Electrical Specifications

    Electrical Specifications
    Type No.

    FT6B45480010

    Frequency Band (MHz)

    4500-4800

    Insertion Loss (dB)(Full temperature,Outcluding connectors)

    0.9max

    Rejection (dB)

    ≥18@4450&4850MHz,≥60@4350&4950MHz,≥70@Below3500&Below5800MHz

    Return Loss (dB)/VSWR

    ≤-18/1.3:1

    Input Power (W)

    <100

    Mechanical Specifications Environmental & Compliance
    Dimensions,HxWxD (mm)

    170x98.5x69.9

    Operational Temperature (°C)

    -40 to +65

    Weight (kg)

    0.8

    Operational Humidity (%)

    ≤95

    Packing Size(mm)

    235x170x120

    Environment

    IP67

    Connector Type

    CPR-229G(input),CPR-229F(output)

    Application

    Indoor and Outdoor

    Color

    Apple White

    RoHS

    Compliant

    Mounting

    Plane mounting

    Finish

    UV resistant Epoxy

    Outline Drawing

    Electrical Specifications

    Type No.

    FT6B37420260

    Frequency Band (MHz)

    3700-4200

    Insertion Loss (dB)(Full temperature,Outcluding connectors)

    0.4,typ.,1.0max

    Rejection (dB)

    ≥70@3000-3600MHz,≥50@3600-3680MHz,

    ≥15@4250-4400MHz, ≥70@4400-5000MHz

    Return Loss (dB)/VSWR

    ≤-18/1.3:1

    Input Power (W)

    <100

    Mechanical Specifications

    Environmental & Compliance

    Dimensions,HxWxD (mm)

    170x98.5x69.9

    Operational Temperature (°C)

    -40 to +65

    Weight (kg)

    0.8

    Operational Humidity (%)

    ≤95

    Packing Size(mm)

    235x170x120

    Environment

    IP67

    Connector Type

    CPR-229G(input),CPR-229F(output)

    Application

    Indoor and Outdoor

    Color

    Apple White

    RoHS

    Compliant

    Mounting

    Plane mounting

    Finish

    UV resistant Epoxy

    Outline Drawing

    • C band 5G filter FT6B374202601

    advantage

    Signal Purity

    Provides uninterrupted and crystal-clear signal reception for broadcast and communication networks, effectively shielding from 5G interference.

    Weather Resistance

    Built to withstand severe weather, ensuring reliable performance in meteorological applications.

    Security Fortification

    Enhances secure communication for defense and security operations, preventing potential signal disruptions.

    Media Stability

    Ensures stable and interference-free transmissions, preserving the accuracy of news broadcasts.

    Military-Grade Isolation

    Offers superior signal isolation for military communications, ensuring reliability and confidentiality.

    Aviation Safety Assurance

    Critical for air traffic communications, maintaining clarity and consistency to promote safe flight operations.

    Uninterrupted Hospitality Services

    Enhances the guest experience by providing reliable satellite TV and communication services without interruption.

    PERFORMANCE CHARACTERISTICS

    The FT6B45480010 stands out with an array of features that make it a dependable and efficient option for reducing 5G signal interference:
