OEM Norsat 5G filter Quality 13000-14500MHz anti-interference ku band 5G filter FT6BA1A10040
Electrical Specifications
| Electrical Specifications | |||
| Type No. |
FT6BA1A10040 |
||
| Frequency Band (MHz) |
13000-14500 |
||
| Insertion Loss (dB)(Full temperature,Outcluding connectors) |
≤0.5 |
||
| Rejection (dB) |
≥30@11.7-12.75GHz,≥70@10.6-10.7GHz,≥50@10.7-12.75GHz |
||
| Return Loss (dB)/VSWR |
≤-19/1.25:1 |
||
| Input Power (W) |
<100 |
||
| Mechanical Specifications | Environmental & Compliance | ||
| Dimensions,HxWxD (mm) |
80x38x38 |
Operational Temperature (°C) |
-40 to +60 |
| Weight (kg) |
<0.3 |
Operational Humidity (%) |
≤95 |
| Packing Size(mm) |
135x75x75 |
Environment |
IP67 |
| Connector Type |
WR75 |
Application |
Outdoor |
| Color |
Gray |
RoHS |
Compliant |
| Mounting |
Plane mounting |
||
| Outline Drawing | |||
Electrical Specifications | |||
Type No. |
FT6B37420260 |
||
Frequency Band (MHz) |
3700-4200 |
||
Insertion Loss (dB)(Full temperature,Outcluding connectors) |
0.4,typ.,1.0max |
||
Rejection (dB) |
≥70@3000-3600MHz,≥50@3600-3680MHz, ≥15@4250-4400MHz, ≥70@4400-5000MHz |
||
Return Loss (dB)/VSWR |
≤-18/1.3:1 |
||
Input Power (W) |
<100 |
||
Mechanical Specifications |
Environmental & Compliance |
||
Dimensions,HxWxD (mm) |
170x98.5x69.9 |
Operational Temperature (°C) |
-40 to +65 |
Weight (kg) |
0.8 |
Operational Humidity (%) |
≤95 |
Packing Size(mm) |
235x170x120 |
Environment |
IP67 |
Connector Type |
CPR-229G(input),CPR-229F(output) |
Application |
Indoor and Outdoor |
Color |
Apple White |
RoHS |
Compliant |
Mounting |
Plane mounting |
Finish |
UV resistant Epoxy |
Outline Drawing | |||
Reliable Media Broadcasting
Supports uninterrupted and interference-free transmissions, maintaining the integrity of news broadcasts.
Military-Grade Signal Isolation
Provides advanced signal protection for military communications, ensuring confidentiality and operational reliability.
Aviation Communication Reliability
Essential for clear and reliable communications between pilots and air traffic controllers, promoting flight safety.
Hospitality Service Stability
Improves guest satisfaction by ensuring continuous satellite TV and communications, free from signal issues.
