OEM Norsat 5G filter Quality 3700-4200MHz anti-interference C band 5G filter FT6B37420130
Electrical Specifications
Electrical Specifications | |||
Type No. |
FT6B37420130 |
||
Frequency Band (MHz) |
3700-4200 |
||
Insertion Loss (dB)(Full temperature,Outcluding connectors) |
1.35 max,1.1 typ |
||
Rejection (dB) |
60 Min below 3680MHz,≥40 Min below 4230MHz, |
||
Return Loss (dB)/VSWR |
≤-20/1.23:1 |
||
Input Power (W) |
<100 |
||
Grorp Delay(ns) |
2.5 nSec Max within±0.5 |
||
Mechanical Specifications |
Environmental & Compliance |
||
Dimensions,HxWxD (mm) |
171.5x98.4x69.9 |
Operational Temperature (°C) |
-40 to +50 |
Weight (kg) |
1 |
Operational Humidity (%) |
≤95 |
Packing Size(mm) |
250x170x130 |
Environment |
IP66 |
Connector Type |
CPR-229G(input),CPR-229F(output) |
Application |
Indoor and Outdoor |
Color |
Apple White |
RoHS |
Compliant |
Mounting |
Plane mounting |
|
|
Outline Drawing | |||
Press and Media Channels
Maintains a stable and reliable communication infrastructure for the media and news industry.
Defense Communication Systems
Offers robust protection for essential military communication networks, preventing signal interference.
Air Traffic Control
Enhances the reliability and stability of communication systems vital to civil aviation.
Lodging Sector
Provides a secure shield for hotel communication networks, protecting them from potential 5G signal interference.
